Blackmagic Design DeckLink 8K Pro G2 Capture Card

Name: Blackmagic Design DeckLink 8K Pro G2 Capture Card
Brand: Blackmagic Design
Price: 855.00 USD
Availability: OutOfStock

Vendor: Blackmagic Design

Blackmagic Design DeckLink 8K Pro G2 Capture Card Unlock professional-grade capture and playback performance with the Blackmagic Design DeckLink 8K Pro G2. Designed for demanding film, broadcast, and post-production workflows, this powerful PCIe...

$855.00

Default Title

Subtotal:

Quantity

Description

Blackmagic Design DeckLink 8K Pro G2 Capture Card

Unlock professional-grade capture and playback performance with the Blackmagic Design DeckLink 8K Pro G2. Designed for demanding film, broadcast, and post-production workflows, this powerful PCIe card supports resolutions from SD and HD through to Ultra HD, 4K, and stunning 8K, giving you the flexibility to work across a wide range of production environments with a single solution.

Featuring four bidirectional 12G-SDI connections alongside HDMI 2.1 input and output, the DeckLink 8K Pro G2 enables versatile multi-channel workflows, allowing simultaneous capture and playback of multiple video streams. Support for high frame rates of up to 120 fps in HD and 4K, and up to 60 fps in 8K, ensures exceptionally smooth motion and detailed image reproduction for high-end productions.

Advanced support for 8-, 10-, and 12-bit colour processing, including full Rec. 2020 colour space compatibility, delivers outstanding colour accuracy and image quality, making it ideal for HDR and professional colour grading workflows. With support for up to 64 channels of embedded audio, the card also provides comprehensive audio integration for complex production requirements.

Compatible with macOS, Windows, and Linux systems, the DeckLink 8K Pro G2 offers a future-ready solution for creators working with high-resolution, high-frame-rate, and high-dynamic-range content, helping streamline production while maintaining exceptional visual and audio fidelity.

Features

8K PCIe Capture & Playback Card
Supports SD, HD, UHD, 4K & 8K Formats
4 x Bidirectional 12G-SDI Ports
HDMI 2.1 Input & Output
4:2:2/4:4:4. 2D/3D Switchable
RS-422 Deck Control
HD & 4K at up to 120 fps
64 Channels Embedded in 4K/8K via SDI
Compatible with macOS, Windows & Linux

Specifications

Inputs/Outputs

Video I/O	Input/Output 4x BNC (12G-SDI) Female Input 1x HDMI 2.1 Female Output 1x HDMI 2.1 Female
Other I/O	Input 1x BNC (Blackburst) Input 1x DE-9/DB-9 (RS-422)

Format Support

Video Resolution	BNC Input/Output (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV) 8192 x 4320 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 7680 x 4320 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 4096 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/100/119.88/120 fps 3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/96/100/119.88/120 fps 2048 x 1080PsF at 50/59.94/60 fps 2048 x 1080 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/96/100/119.88/120 fps 1920 x 1080PsF at 50/59.94/60 fps 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/96/100/119.88/120 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 720 x 480i at 59.94 fps 720 x 576i at 50 fps HDMI Input/Output (8/10/12-Bit 4:4:4/4:2:2/4:2:0) 8192 x 4320 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 7680 x 4320 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 4096 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/95/96/100/119/120 fps 3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/95/96/100/119/120 fps 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60/95/96/100/119/120 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 720 x 480i at 59.94 fps 720 x 576i at 50 fps
Audio Format	Unspecified Digital Signal Input/Output: 48 kHz / 24-Bit
Embedded Audio	SDI Input: 64-Channel SDI Output: 64-Channel HDMI Input: 32-Channel HDMI Output: 32-Channel

Standards

Video Standard Compliance	SMPTE: 259M/274M/292M/296M/372M/424M/425M/425M-A/425M-B/2048-1/ST 2081-10/ST 2082-11/ST 2082-12
HDR Support	Yes: Hybrid Log Gamma
Broadcast System Compatibility	NTSC, PAL

Hardware

OS Compatibility

macOS 13.0 or Later
Windows 10 or Later (64-Bit Only)
Linux

Power

Power Consumption

30 W

General

Operating Conditions	41 to 122°F / 5 to 50°C up to 90% Humidity
Storage Conditions	-4 to 140°F / -20 to 60°C up to 90% Humidity
Dimensions	6.41" / 16.28 cm
Weight	10.4 oz / 295 g
