Elation Artiste DaVinci; 270W Pro LED Spot MH (EAD582)

Elation Artiste DaVinci; 270W Pro LED Spot MH (EAD582)

The Elation Artiste DaVinci is professionally designed featuring a new 270W LED Cool White LED engine that is made along with the advanced optics capable to deliver over 12,000 total lumens, full CMY color mixing and linear CTO color correction, ultra wide 6° to 48° zoom, 6 rotating glass and 9 static-stamped metal interchangeable gobos, 7 dichroic colors that includes CTB and Violet, full 360° bi-directional animation wheel, 3-facet and linear rotating prisms, frost filter, auto-focus, motorized iris and focus, variable dimming curve modes, hibernation mode, high speed electronic shutter and strobe, RDM (Remote Device Management), DMX, sACN protocol support, and Art-NET, Elation's E-FLY™ internal wireless DMX transceiver, power in/out connections, locking 5pin XLR DMX, RJ45 ethernet, full color 180° reversible menu display with 6 button touch control panel, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, battery backup for display power, and a multi-voltage universal auto switching power supply (100-240v).

Features

• 270W Cool White 12,000 Lumen LED Spot Luminaire
• 6° to 48° Motorized Zoom
• Full CMY Color Mixing and Linear CTO Color Correction
• 7 Dichroic Colors including CTB and Violet
• 6 Rotating and 9 Static-Stamped Interchangeable Gobos
• 3-Facet and Linear Rotating Prisms and Frost Filter
• Full 360° Bi-Directional Animation Wheel
• High Speed Electronic Shutter and Strobe
• Motorized Iris, Focus, and Auto-Focus
• Variable Dimming Curve Modes
• DMX, RDM, Art-NET, and sACN Protocol Support
• Elation's E-FLY™ Internal Wireless DMX Transceiver
• Low Heat, Quiet Operation, Hibernation Mode
• Adjustable LED Refresh Rate Frequency and Gamma
• Flicker Free Operation For Broadcast TV and FILM

SOURCE

270W Cool White LED Engine

50,000 Hour Average LED Life*

^{*Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.}

PHOTOMETRIC DATA

12,000 Total Lumen Output

CRI 72+

EFFECTS

6° - 48° Motorized Zoom

3-Facet and Linear Rotating Prisms and Prism Macros

Full 360° Bi-Directional Rotating Animation Wheel

Frost Filter Hybrid Wash Effect

Motorized Zoom, Iris, Focus and Auto-Focus

High Speed Electronic Shutter and Strobe

Variable 16-Bit Dimming Curve Modes

Adjustable LED Refresh Rate Frequency and Gamma Brightness

COLOR

7 Dichroic Colors + CTB

Full CMY Color Mixing

Linear CTO Color Correction

GOBOS

2 Gobo Wheels

6 Interchangeable Rotating / Indexing Gobos

9 Interchangeable Static-Stamped Metal Gobos

CONTROL / CONNECTIONS

(3) DMX Channel Modes (40 total channels)

6 Button Touch Control Panel

Full Color 180° Reversible LCD Menu Display

8 / 16 Bit Resolution Adjustable Movement

DMX, RDM, Art-Net, sACN Protocol Support

Elation's E-FLY™ Internal Wireless DMX Transceiver

Locking 5pin XLR DMX, RJ45 Ethernet, and Power

With Wired Digital Communication Network

SIZE / WEIGHT

Length: 16.4" (416mm)

Width: 11.2" (284mm)

Vertical Height: 25.4" (645mm)

Weight: 56.0 lbs. (25.4kg)

ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz

470W Max Power Consumption

14°F to 113°F (-10°C to 45°C)

APPROVALS / RATINGS

CE | cETLus | IP20

FIRMWARE UPDATES

Current Version: V1.2.8

Click HERE for software updates.
