Sony Professional VPL-CH370, 5,000 lumens WUXGA 3LCD Basic Installation projector
Vendor: Sony
Available
Sony Professional VPL-CH370, 5,000 lumens WUXGA 3LCD Basic Installation projector
The Sony Professional VPL-CH370 delivers an outstanding brightness of 5000 lumens and ultra high-quality images with WUXGA resolution. Sony 3LCD BrightEra™ panel technology provides higher picture quality, substantially brighter images, higher efficiency, consistent color stability, and longer durability. It also delivers installation flexibility, environment-friendly features, and a low total cost of ownership, in a stylish design that blends into any decor. The lens shift/zoom capability and the image correction features easily allow users to fit any image onto the screen, even from an offset projection angle. In addition, the projector is economically designed for optimum energy efficiency, thanks to its energy-saving features, and has all the features and functionality that you would expect from Sony, particularly in terms of installation, projection, usability, and maintenance.
SONY PROFESSIONAL VPL-CH370 MAIN FEATURES
-
High-resolution WUXGA image
The VPL-CH370 delivers an amazing resolution of WUXGA (1920 x 1200). Extremely clear and detailed high-quality images are projected, even on a large screen. The VPL-CH370 is the ultimate tool for projecting images in a range of applications requiring exceptional detail.
-
Fine lens shift: +/- 5%, Horizontal: +/- 4%
The VPL-CH370’s lens shift range adjustment means that the projector can be positioned picture-perfect and horizontally offset to avoid any minor ceiling obstacles.
-
Blend-in design
The VPL-CH370 has a low-profile chassis, so it appears to blend into the ceiling or wall on which it is mounted.
-
High image quality 3LCD BrightEra™ natural and vivid color images with high brightness of 5000 lumens
Thanks to the optical system projecting three basic colors constantly, the projector offers excellent light efficiency, which ensures colorful and bright images. Sony's BrightEra™ panels deliver improved panel light resistance, higher resolution, high brightness, and increased panel reliability. High color reproducibility is important, especially when using colorful content, such as materials used in classrooms.
-
1.5:1 to 2.2:1 throw ratio
The VPL-CH370 offers a 1.5:1 to 2.2:1 throw ratio that can accommodate most large classrooms or large meeting room’s current replacement installation.
-
Advanced energy-saving features
Advanced lamp technology enables robust energy-saving features. For example, greater brightness control in Auto Light Dimming mode saves considerable energy when the projector is left on without being used. During projection, Auto Picture Mode automatically adjusts light output to suit the projected scene. When you need to mute the picture temporarily, light output can be completely deactivated to minimize energy consumption.
Display System | 3-Chip 0.64" LCD |
Native Chip Resolution | 1920 x 1200 (WUXGA) |
Supported Resolutions | Maximum: WUXGA - 1920 x 1200 |
Max Brightness | 4000 Lumens 3200 Lumens 2600 Lumens |
Aspect Ratio | 16:10 |
Contrast Ratio | 2500:1 |
Scan | Horizontal: 19 to 92 kHz Vertical: 48 to 92 Hz |
Focus | Manual |
Lens Shift | Vertical: ± 5% Horizontal: ± 4% |
Optical Zoom | Manual: 1.45x |
Throw Ratio | 1.5 to 2.2:1 |
Projection Size | 40 - 300" / 101.60 - 762.00 cm |
Keystone Correction | Vertical: ± 30° Horizontal: ± 20° |
Built-In Speaker | Yes (Mono) |
Speaker Power | 12W |
Closed Captioning | Yes |
Inputs/Outputs | 1 x VGA (DE-15/DB-15) Video Output 1 x Ethernet (RJ45) LAN Input 2 x HDMI (HDMI Type-A) Audio, Video Input 1 x VGA (DE-15/DB-15) Video Input 1 x USB 2.0 (USB Type-A) Data 1 x USB 2.0 (USB Type-B) Data 1 x 2RCA Audio Input 1 x Composite (RCA) Video Input 1 x S-Video (4-Pin DIN) Video Input 1 x 1/8" / 3.5 mm Mini Audio Input 1 x 1/8" / 3.5 mm Mini Microphone Input 1 x 1/8" / 3.5 mm Mini Audio Output 1 x RS-232 (DE-9/DB-9) Control |
Light Source | Lamp (1 x UHM) |
Lamp Power | 250 W |
Expected Lamp Life | Full Brightness: 3000 Hours Medium Brightness: 4000 Hours Low Brightness: 5000 Hours |
Supported Languages | Arabic Dutch English Finnish French German Greek Hungarian Indonesian Italian Japanese Korean Norwegian Polish Portuguese Russian Simplified Chinese Spanish Swedish Thai Traditional Chinese Turkish Vietnamese |
AC Input Power | 120 to 240 VAC, 50 / 60 Hz |
Heat Dissipation | 1204 BTU |
Power Consumption |
Full Brightness: 353 W Medium Brightness: 285 W Low Brightness: 265 W Standby Mode (Lamp Off): 4.7 W Standby Mode (Lamp Off): 0.5 W |
Dimensions (W x H x D) | 16.0 x 4.4 x 13.0" / 406.0 x 113.0 x 330.5 mm Without Protrusions |
Weight | 12.00 lb / 5.44 kg |
