Biamp Systems EX-S10SUB 10-inch Indoor/Outdoor Surface Mount Subwoofer | Black, White

Vendor: Biamp Systems
Biamp Systems EX-S10SUB 10-inch Indoor/Outdoor Surface Mount Subwoofer | Black, White The Desono EX-S10SUB Surface Mount Subwoofer is a high-performance 10-inch subwoofer engineered to extend the low-frequency performance of Desono EX-S6 and EX-S8...
$970.00
Color
Black
White

Biamp Systems EX-S10SUB 10-inch Indoor/Outdoor Surface Mount Subwoofer | Black, White

The Desono EX-S10SUB Surface Mount Subwoofer is a high-performance 10-inch subwoofer engineered to extend the low-frequency performance of Desono EX-S6 and EX-S8 loudspeakers. Delivering deep, impactful bass, it creates a full-range audio solution ideal for foreground music, enhancing the listening experience in commercial environments where rich, balanced sound is essential. Designed with a discreet enclosure that matches the EX Series loudspeakers, the EX-S10SUB blends seamlessly into its surroundings while delivering powerful low-frequency output. Its compact, architecturally friendly design makes it easy to integrate into hospitality venues, retail spaces, restaurants, bars, corporate environments, educational facilities, and other distributed audio applications. Installation is quick and flexible with Biamp's patented ClickMount™ mounting system. The ClickMount Pan-Tilt Bracket enables precise speaker positioning with indexed aiming and supports both vertical and horizontal mounting without repositioning the bracket. For low-profile or outdoor installations, the optional ClickMount U-Bracket includes the ClickPlug™ with an integrated gland nut, providing weather-resistant cable entry for reliable performance in exposed environments. Both mounting options feature theft- and tamper-resistant designs for enhanced security. Built to complement the Desono EX Series, the EX-S10SUB delivers powerful bass, flexible installation, and a clean, professional appearance, making it the perfect addition to commercial audio systems requiring enhanced low-frequency performance.

Key Features

  • Certified for use with Zoom software
  • Exceptional audio clarity with discreet styling
  • Easy to install with two mounting options
  • Low frequency boost for distributed applications
  • ETL listed to comply with UL 1480A, CSA 62368-1, CE marked, and RoHS compliant
  • 5-year warranty
GENERAL
Height 20.82 inches (529 mm)
Width 12.17 inches (309 mm)
Depth 17.28 inches (439 mm)
Weight 28.26 lbs (12.8 kg)
Finish RAL Color: Black RAL 9017
Material Grille:
Powder-coated perforated Marine Grade aluminum backed with hydrophobic cloth.
Enclosure:
High-impact UL94 5VB rated polycarbonate/ABS blend, painted UV resistant matte finish
Bracket: Heavily reinforced glass-filled nylon with UV-resistant painted matte finish cover
Mounting ClickMount pan-tilt bracket or ClickMount U-Bracket
Included Accessories CMX-LG [-B,-W] - Large ClickMount Pan-tilt Bracket Kit
EXUB-S10 [-B,-W] - EX-S10 ClickMount U-Bracket kit
Recommended Amplifiers 300 W - 600 W, 8 Ω (49 V - 69 V)
ENVIRONMENTAL
Operating Environment Indoor/Outdoor
POWER
Power 300W Cont.
1200W Peak
LOUDSPEAKER
Loudspeaker Type 10-inch surface mount subwoofer
Operating Mode Passive, low impedance
Operating Range 38 Hz - 140 Hz
Beamwidth Omnidirectional
Transducers LF 1 x 10 inches (250 mm) treated paper cone
Sensitivity (1W/1m) 89 dB
Signal Processing Required Processing: 35 Hz, 18 dB high-pass filter; DSP preset
Drivers LF 1 x 10 inches
AUDIO
Impedance
Maximum Output 112 dB
118 dB Peak
(UXO 80 Hz)
CERTIFIED SOLUTIONS
Zoom Zoom Certified
COMPLIANCE
Certifications ETL listed to comply with UL 1480A
CSA STD C22.2# 62368-1
Environmental Ratings IP54 per IEC 60529
IEC 60068-2-5 (Solar Radiation)
IEC 60068-2-11 (Salt Mist)
IEC 60068-2-42 (SO2)
IEC 60068-2-60 (Chlorine)
