Turbosound TCS115B-R (Black) / TCS115B-R-WH (White) 15'' Front Loaded Subwoofer for Installation Applications (Weather Resistant)

Vendor: Turbosound
Description Turbosound TCS115B-R (Black) / TCS115B-R-WH (White) 15'' Front Loaded Subwoofer for Installation Applications (Weather Resistant) The Athens TCS115B-R 15" Front-Loaded Weather-Resistant Subwoofer that is professionally designed by Turbosound is carefully crafted for a wide range...
$850.00
Color
Black
White

Turbosound TCS115B-R (Black) / TCS115B-R-WH (White) 15'' Front Loaded Subwoofer for Installation Applications (Weather Resistant)

The Athens TCS115B-R 15" Front-Loaded Weather-Resistant Subwoofer that is professionally designed by Turbosound is carefully crafted for a wide range of fixed installation and portable PA applications. It comes in different color variants: TCS115B-R (Black) / TCS115B-R-WH (White), It is capable of providing optimal low frequency reinforcement during the time it is used in conjunction along with all TCS series loudspeakers. This IP54-rated weather-resistant subwoofer is made to be suitable for outdoor use.

The subwoofer comes featuring an enclosure that comes with a bass reflex port and a double suspension 15" low frequency driver that is capable of utilizing a specialized voice coil wound on both inside and outside of the coil former. This is resulting in higher magnetic density, better heat dissipation, higher power handling capacity, and improved efficiency. The Athens TCS115B-R is designed for providing fast and accurate transient response intended for virtually distortion-free operation even in the most demanding applications.

The subwoofer's cabinet is carefully constructed from 5/8" (15mm) birch plywood and comes including a rugged powder coated perforated steel mesh grille backed with reticulated foam. Multiple internal rigging points are made for allowing the bracket mount and suspension in many different configurations in permanent installations. An array of two or more cabinets is capable to be configured with the use of Turbosound fly plates and coupler kits (sold separately). Connectivity is provided in the form of a captive cable tail, which is designed for entering the cabinet by means of a sealed cable gland on an aluminum panel.

  • Front-loaded subwoofer for installation applications
  • 500W continuous, 2,000W peak power
  • IP54-rated weather-resistant components for outdoor use
  • Double suspension 15" low frequency driver with inside/outside wound coil
  • Low distortion bass reflex port design
  • 5/8" (15mm) birch plywood enclosure with durable semi matte black paint finish
  • Architecturally styled powder coated perforated plated steel mesh grille with foam backing
  • Multiple internal rigging points allow bracket mount and suspension in many different configurations
  • Captive cable tail with sealed cable gland on aluminum connector panel
  • Designed and engineered in England
System
Frequency Response 45 Hz to 150 Hz, ±3 dB
40 Hz to 200 Hz, -10 dB
Nominal Dispersion Half space
Power Handling 500 W continuous, 2,000 W peak
Sensitivity 97 dB (1 W @ 1 m)
Maximum SPL 124 dB continuous, 130 dB peak
Impedance 8 Ohms
LF Driver Size 1 x 15" (387 mm)
Enclosure
Connectors 2-core capacitive tail
Wiring Passive: Red/blue input + / -
Construction 5/8" (15 mm) birch plywood
Weather Resistance IP54-rated
Grille Powder-coated perforated steel
Rigging Points 8 x M10
Dimensions (H x W x D) 32.9 x 18.5 x 17.8" (834 x 469 x 452 mm)
Weight 74.7 lb (33.9 kg)
