Yamaha CXR10MKIII Passive 10 inch full range loudspeaker black plastic ABS
Vendor: Yamaha
Unavailable
Yamaha CXR10MKIII Passive 10 inch full range loudspeaker black plastic ABS
Designed for wedding and event DJs, live venues, and rental companies, the Yamaha CXR10mkIII is the third-generation evolution of Yamaha’s passive 2-way loudspeaker lineup. Featuring refined port design, newly developed transducers, and passive operation with up to 1100W peak power handling, it delivers clear, powerful sound with optimized low-end response and controlled high-frequency performance.
The Yamaha CXR10mkIII also introduces an updated horn and port design for enhanced acoustic accuracy. Its lightweight, high-performance molded enclosure and rubber-coated handles make transport and setup easier, while flexible mounting options include dual-angle pole mounting, suspended rigging through M10 and M8 points, and floor monitor positioning at a 55° angle.
Equipped with an improved 10-inch low-frequency cone and a 1.75-inch compression driver, the Yamaha CXR10mkIII is engineered for optimized audio performance. When paired with Yamaha PX and PC-D series amplifiers, users can unlock advanced Yamaha speaker processing for greater control and sound quality.
Features
- For DJs, Live Performances, and Events
- Molded Bass-Reflex ABS Cabinet
- 1100W Peak Power Handling
- 10" LF Driver, 1.75" HF Driver
- Enhanced HF Directivity / LF Response
- 4-Pole speakON I/O
- Supports Yamaha Speaker Processing
- Rigging, Pole, and Floor Monitor Support
- Rubber-Coated Handles
- Symmetrical Design for Mirroring
| Speaker Type | Passive Loudspeaker |
| Configuration | 2-Way |
| Total Passive Power Handling | 550 W Program / 1100 W Peak |
| Nominal Impedance | 8 Ohms |
| LF Driver |
1x 10" / 25.4 cm Cone Voice Coil: 2.5" / 6.3 cm |
| HF Driver |
1x 1.75" / 4.45 cm Compression Driver Throat: 1" / 2.5 cm |
| Frequency Range/Response | 54 Hz to 20 kHz |
| Speaker Type | Passive Loudspeaker |
| Configuration | 2-Way |
| Enclosure Type | Bass-Reflex |
| Total Passive Power Handling | 550 W Program / 1100 W Peak |
| Constant Voltage / Transformer Taps | No |
| Nominal Impedance | 8 Ohms |
| LF Driver |
1x 10" / 25.4 cm Cone Voice Coil: 2.5" / 6.3 cm |
| HF Driver |
1x 1.75" / 4.45 cm Compression Driver Throat: 1" / 2.5 cm |
| Frequency Range/Response | 54 Hz to 20 kHz |
| Maximum SPL | 123 dB SPL |
| Speaker Sensitivity | 93 dB SPL |
| Coverage Angle | 90° H x 60° V |
| Crossover Frequency | 2000 Hz |
| Dynamic Processing | No |
| Audio I/O |
1x speakON NL4 Speaker Input 1x speakON NL4 Speaker Output |
| Color | Black |
| Mounting |
2 x 1.38" / 35 mm Pole Socket (Bottom)2 x M8 (Top) 1 x M6 (Rear) 2 x M8 (Bottom) 2 x M8 (Side) |
| Handles | 1x Top |
| Construction Material | ABS |
| Environmental Resistance | No |
| Dimensions | 19.8 to 12.2 x 12.2" / 50.3 to 31 x 31 cm |
| Weight | 26.9 lb / 12.2 kg |
