Microtech Gefell M 330 Small-Diaphragm Wide-Cardioid Condenser Microphone with Extended Accessories (Matched Pair, Dark Bronze)

Vendor: Microtech Gefell
Microtech Gefell M 330 Small-Diaphragm Wide-Cardioid Condenser Microphone with Extended Accessories (Matched Pair, Dark Bronze) The small-diaphragm microphone series M 300 now includes microphones with four distinct polar patterns for high-quality recordings, thanks...
$2,760.00
Title

Microtech Gefell M 330 Small-Diaphragm Wide-Cardioid Condenser Microphone with Extended Accessories (Matched Pair, Dark Bronze)

The small-diaphragm microphone series M 300 now includes microphones with four distinct polar patterns for high-quality recordings, thanks to the addition of the new M 330 with wide-cardioid polar pattern. The series is a system for multiple applications, ranging from a single microphone to stereo/surround and 3D audio, when combined with intelligent accessories. The Microtech Gefell M 330 is made for professional and semiprofessional markets for use in studio settings for live performances, recording of instruments, vocals, speech, and sound reinforcement. It can also be used in unfavorable acoustic environments, like churches.

Key Features

  • Wide-Cardioid Polar Pattern
  • Pressure-Gradient Design
  • Transformerless Circuitry
  • Small-Diaphragm Capsule
  • 20 Hz to 20 kHz Frequency Response
  • Smooth Treble Boost
  • Low Noise, High Dynamic Range
  • 48 VDC Phantom Powered
  • XLR 3-Pin Output
  • Includes Two KS25 Stereo Rails and Case
Microphone
Primary Applications Live Sound, Studio Recording
Form Factor Small Diaphragm
Intended Sound Sources Vocals, Instruments
Sound Field Mono
Element Type Condenser
Polar Pattern Subcardioid/Wide Cardioid
Orientation End Address
Circuitry Solid-State
Pad No
High-Pass Filter No
Gain Adjustment No
On-Board Controls No
Performance
Frequency Range 20 Hz to 20 kHz
Maximum SPL 147 dB SPL
Impedance 100 Ohms
Sensitivity 12 mV/Pa at 1 kHz
Dynamic Range 131 dB
Signal-to-Noise Ratio 68 dB CCIR
78 dB A-Weighted
Equivalent Noise Level 26 dB CCIR
16 dB A-Weighted
Connectivity
Analog Output 1x XLR 3-Pin
Power
Power Sources Phantom Power
Operating Voltage 48 V
Physical
Color Bronze
Mounting Thread Size 3/8"-16 Female
Dimensions ø: 0.83 x L: 5.12" / ø: 21 x L: 130 mm (Microphone)
Weight 4.44 oz / 126 g (Microphone)
