Turbosound TLX84 Front View

Turbosound TLX84, Dual 2 Way 8" Line Array Element for Portable and Fixed Installation Applications

Vendor: Turbosound
Descriptions Turbosound TLX84, Dual 2 Way 8" Line Array Element for Portable and Fixed Installation Applications The Turbosound TLX84 is a 2-way full range and a compact biamplified dual 8" 1,800-Watt line array...
$1,239.00
Title
Descriptions

Turbosound TLX84, Dual 2 Way 8" Line Array Element for Portable and Fixed Installation Applications

The Turbosound TLX84 is a 2-way full range and a compact biamplified dual 8" 1,800-Watt line array element that is perfectly suited to a wide range of speech and music sound reinforcement applications in fixed installation, portable and touring audio systems. The Turbosound TLX84 is engineered to work in conjunction with LAKE DSP and LAB GRUPPEN amplification, giving an optimal FOH performance, as well as offering considerable flexibility to readily adapt to varying venue requirements. An integral suspension system designed to meet BGV-C1 specifications is provided for suspending or ground stacking multiple TLX84 elements with a 10:1 safety factor. Designed for speed and simplicity of use, custom-engineered flybars and road cases are available as separate accessories. The companion TLX215L dual 15" subwoofer is specifically designed for use with Turbosound TLX84, giving additional low frequency extension and substantial impact for more demanding sound reinforcement applications. Also, the Turbosound TLX84 is finished in hard wearing semi matt black paint, the Turbosound TLX84 cabinet is built from 15 mm (5⁄8") birch plywood and includes a rugged powder coated perforated steel mesh grille backed with reticulated foam. The rear panel connector plate of the Turbosound TLX84 carries Neutrik speakON* NL4 connectors for input and link connections to additional enclosures.

Turbosound TLX84 Main Features
  • 2-way line array element for portable and fixed installation application
  • 450 Watts continuous, 1,800 Watts peak power
  • Ideal for FOH, center cluster, offstage fill, stereo in-fill or distributed fill applications
  • Dual 8" LF drivers with weather-resistant cones
  • Dual titanium dome 1" copper-clad aluminium coil compression driver
  • Integral rigging system for suspending or ground-stacking multiple TLX84 elements
  • Wide 100° H x 10° V dispersion for even coverage
  • Bi-amp operation for high output and controlled dispersion
  • 5/8" (15mm) birch plywood enclosure with hard-wearing, semi-matt black paint finish
  • Powder-coated, perforated steel-mesh grille
  • Neutrik speakON NL4 connectors for reliable long-life operation
  • Compatible with TLX215L dual 15" subwoofer
  • 10-Year Warranty Program (contact your Sales Pro for further details)
  • Designed and engineered in the U.K.
Specifications

System

Frequency Response 67 Hz – 20 kHz ±3 dB
58 Hz – 20 kHz -10 dB
Nominal Dispersion 100° H x 10° V @ -6 dB points
Power Handling (IEC) LF: 450 W continuous, 1,800 W peak
HF: 60 W continuous, 240 W peak
Sensitivity LF: 94 dB (1 W @ 1 m)
HF: 101 dB (1 W @ 1 m)
Maximum SPL LF: 121 dB continuous, 127 dB peak
HF: 119 dB continuous, 125 dB peak
Impedance LF: 16 O
HF: 16 O
Crossover Type External bi-amp
Components 2 x 8"" (203 mm) LF driver
2 x 1"" (25.4 mm) HF compression driver

Enclosure

Connectors 2 x Neutrik speakON* NL4
Wiring Pins 1+ / 1- LF, pins 2+ / 2- HF
Dimensions H x W x D 245 x 801 x 485 mm (9.6 x 31.5 x 19.1")
Net Weight 27.9 kg (61.4 lbs)
Construction 15 mm (5 / 8") plywood
Finish Semi matt black paint
Grille Powder coated perforated steel
Suspension Hardware Integral variable curvature

Accessories

TLX84-FLB fly bar
TLX84-RC4 road case
