Blackmagic Design BMD-CONVMCAUDS4K Mini Converter - Audio to SDI 4K

Vendor: Blackmagic Design
Description Blackmagic Design BMD-CONVMCAUDS4K Mini Converter - Audio to SDI 4K The Blackmagic Design BMD-CONVMCAUDS4K, also named Mini Converter - Audio to SDI 4K, is professionally designed capable of giving you the ability of embedding four channels...
$325.00
Title

Blackmagic Design BMD-CONVMCAUDS4K Mini Converter - Audio to SDI 4K

The Blackmagic Design BMD-CONVMCAUDS4K, also named Mini Converter - Audio to SDI 4K, is professionally designed capable of giving you the ability of embedding four channels of analog audio or eight channels of AES/EBU digital audio into any SDI video signal. It is built featuring a 6G-SDI input that is accepting resolutions up to Ultra HD (3840x2160) and DCI 4K (4096x2160), and it is capable of providing four 1/4" audio jack connectors for inputting and embedding your analog or digital audio channels. The SDI signal that comes along with embedded audio is output over a single 6G-SDI connector, with the resolution and frame rate matching the original input source.

With the use of 6G-SDI technology, the Mini Converter - Audio to SDI 4K is capable of supporting UHD and DCI 4K resolutions at up to 30 fps. The Mini Converter is also capable of supporting Single Link SD, HD, and 3G-SDI signals, automatically detecting and switching between the different formats. A redundant SDI input is also provided as an optional back up; with the converter switching over if the main SDI input is lost.

The Mini Converter's settings are controlled with the use of the built-in DIP switches or using USB with the use of the included software for Max OS X or Windows computers. The USB port also enables the firmware to be updated. For powering the device, a 12 VDC power supply is included with international socket adapters.

Features

  • 4:2:2 and 4:4:4 sampling and color precision
  • 24-bit, 48 kHz audio sampling
  • Compliant with SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE ST-2036, ITU-R BT.656 and ITU-R BT.601
SDI Video Input 1 x SD/HD/3G/6G-SDI
1 x SD/HD/3G/6G-SDI-SDI redundant input
SDI Video Output 1 x SD/HD/3G/6G-SDI
Audio Input 4 x 1/4" jacks
4 channels of balanced analog audio, or 8 channels of AES/EBU balanced digital audio
Multi-Rate Support Auto detection of SD, HD, 2K, UHD, and 4K signals
Reclocking Yes
Format Support SD:
NTSC 525/29.97 and 525/23.98
PAL 625/25

HD:
720p 59.94/60
1080i 50/59.94/60
1080PsF 23.98/24/25/29.97/30
1080p 23.98/24/25/29.97/30/50/59.94/60

2K:
2048x1080PsF 23.98/24/25
2048/1080p 23.98/24/25

UHD/4K
3840x2160p 23.98/24/25/29.97/30
4096x2160p 23.98/24/25/29.97/30
SDI Compliance SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE ST-2036, ITU-R BT.656, and ITU-R BT.601
SDI Video Rates Switchable between SD, HD, 3G, and 6G-SDI
SDI Auto Switching Automatically detects SD, HD, 3G, or 6G-SDI
SDI Video Sampling 4:2:2, 4:4:4
SDI Audio Sampling 24-bit, 48 kHz
SDI Color Precision 4:2:2, 4:4:4
SDI Color Space YUV, RGB
Settings Control DIP switches or USB software for Mac OS X and Windows
Firmware Upgradeable Via USB 2.0
Power Supply 12 VDC
Power Consumption 8.4 W
Operational Voltage Range 12 to 31 VDC
Operating Temperature 32 to 104° F (0 to 40 ° C)
Storage Temperature -4 to 113° F (-20 to 45 ° C)
Relative Humidity 0 to 90% non-condensing
Dimensions 4.52 x 3.63 x 0.90" (11.48 x 9.22 x 2.29 cm)
Weight 7.61 oz (215.74 g)
