Blackmagic Design Micro Converter HDMI to SDI 12G

Blackmagic Design Micro Converter HDMI to SDI 12G

The Blackmagic Micro Converter HDMI to SDI 12G is a compact, high-performance converter that allows you to connect HDMI cameras, computers, and media devices to professional 12G-SDI broadcast equipment. Designed for live production, broadcasting, AV installations, and filmmaking, it delivers reliable HDMI-to-SDI conversion while supporting high-resolution workflows up to DCI/UHD 4K at 60 fps. Featuring one HDMI input and two 12G-SDI outputs, the converter enables you to distribute a single HDMI source to multiple SDI monitors, switchers, or recorders simultaneously. It's also an ideal solution for extending HDMI signals over long distances using robust SDI cabling, ensuring dependable performance in studios, event venues, and production environments.

The converter automatically detects the incoming HDMI signal and converts it to the appropriate SDI format, supporting SD, HD, 3G, 6G, and 12G-SDI standards. When operating in 3G-SDI, both outputs can be configured for Level A or Level B, providing broad compatibility with professional broadcast systems. Built for demanding workflows, the converter features SDI re-clocking to maintain signal integrity over long cable runs, HDMI timecode support for accurate synchronization, and support for a wide range of broadcast frame rates, including cinema-style 48 fps. It also supports HDMI copy protection, ensuring compatibility with protected HDMI sources where applicable.

Housed in a rugged metal enclosure, the converter is built for reliable operation in both studio and field productions. Integrated LED indicators provide instant visual confirmation of power and signal status for quick setup and troubleshooting.The convenient USB-C port allows the converter to be powered from USB adapters, monitors, laptops, desktop computers, or other compatible USB power sources, while also enabling fast firmware updates on Windows and macOS systems. An optional USB-C power supply can be used for standalone operation.

Whether you're integrating HDMI cameras into SDI broadcast systems, distributing 4K video to professional equipment, or extending HDMI signals across long distances, the Blackmagic Micro Converter HDMI to SDI 12G delivers dependable, broadcast-quality performance in an ultra-compact design.

Features

• 1 x HDMI Input, 2 x 12G-SDI Outputs
• Selectable SD/HD Level A/B SDI Ports
• Supports up to DCI 4K60 Resolution I/O
• SDI Re-Clocking, HDMI Copy Protection
• Automatic Input Signal Detection
• Compact, Rugged Design
• Embedded Audio, USB Type-C Power
• LED Video & Power Signal Indicators
