Blackmagic Design URSA Cine 12K LF Camera (PL Mount)

Vendor: Blackmagic Design
Blackmagic Design URSA Cine 12K LF Camera (PL Mount) Bring cinematic storytelling to the highest level with the Blackmagic Design URSA Cine 12K LF Camera, a next-generation digital cinema camera designed for feature...
$17,045.00
Title

Blackmagic Design URSA Cine 12K LF Camera (PL Mount)

Bring cinematic storytelling to the highest level with the Blackmagic Design URSA Cine 12K LF Camera, a next-generation digital cinema camera designed for feature films, premium television, commercials, and virtual production. Built around a revolutionary 12K full-frame 36 x 24mm sensor, the URSA Cine 12K LF delivers extraordinary image quality, incredible detail, and the flexibility required for the most demanding professional productions. The advanced sensor captures stunning 12K footage with an impressive 16-stop dynamic range, preserving exceptional detail across highlights and shadows for greater creative control in colour grading and visual effects. Combined with Blackmagic RAW recording up to 12K 3:2 Open Gate, the camera provides maximum image fidelity while maintaining an efficient, professional post-production workflow.

Designed for today's connected productions, the URSA Cine 12K LF features built-in Wi-Fi and SRT live streaming, allowing high-quality video transmission for remote monitoring, live broadcasting, and collaborative workflows. High-speed networking further enhances efficiency by enabling fast access to cloud storage and M.2 SSD media, helping production teams transfer, back up, and share footage with minimal downtime. Integrated motorised ND filters make it easy to adapt to changing lighting conditions while maintaining consistent exposure and the desired cinematic depth of field. Professional LEMO and Fischer power and control connections ensure seamless integration with industry-standard accessories, remote control systems, and studio equipment, making the camera equally suited for handheld, studio, and large-scale production environments.

Supplied with an industry-standard ARRI PL lens mount, the URSA Cine 12K LF is ready to support a wide range of professional cinema lenses, giving filmmakers the creative flexibility and optical performance expected in high-end productions. Combining ultra-high-resolution 12K capture, advanced networking, professional connectivity, and exceptional dynamic range, the Blackmagic Design URSA Cine 12K LF Camera is built to meet the demands of modern cinematic production while helping creators achieve uncompromising visual excellence.

Please Note: EVS and shown accessories is not included

Features

  • Large Format Full-Frame 12K Sensor
  • 16 Stops of Dynamic Range
  • Blackmagic RAW up to 12K 3:2 Open Gate
  • Stream via RTMP/SRT via Wi-Fi/RJ45/USB-C
  • Built-In Clear, 2/4/6-Stop IRND Filters
  • Built-In Folding 5" 1500 cd/m² Monitor
  • 12G-SDI Output, USB-C Expansion Ports
  • Timecode/REF, LEMO/Fischer Control Ports
  • 2 x Balanced 3-Pin XLR Audio Inputs
  • Optional EVF
Key Specs
Lens Mount Interchangeable Mount with Included ARRI PL
Image Sensor Full-Frame
Effective Sensor Resolution 98 Megapixel (12,288 x 8040)
Image Stabilization No
Max Recording Modes Blackmagic RAW
Up to 12K up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00/80 fps
Max Video Output via HDMI / SDI/BNC
Up to UHD 4K
Media/Memory Card Slot No
Mobile App Compatible Yes: iOS Only
Functionality: Remote Control
Battery B-Mount
Imaging
Lens Mount Interchangeable Mount with Included ARRI PL
Lens Communication Yes
Image Sensor 35.64 x 23.32 mm (Full-Frame) CMOS
Effective Sensor Resolution 98 Megapixel (12,288 x 8040)
Image Stabilization No
Built-In ND Filter Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Built-In CC Filter No
Internal Filter Holder No
Capture Type Video Only
Exposure Control
Shutter Type Mechanical Focal Plane Shutter and Electronic Rolling Shutter
Advertised Dynamic Range 16 Stops
Focus
Focus Mode Automatic, Full-Time Servo, Manual Focus
Video Capture
Internal Recording Blackmagic RAW
12288 x 8040 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00/80 fps (90 to 1432 MB/s)
9648 x 8040 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
12288 x 6912 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00/100 fps
12288 x 6480 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
7680 x 6408 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
9408 x 6264 up to 23.98/24.00/25/29.97/30.00/59.94/60.00/100 fps (54 to 856 MB/s)
8192 x 5360 up to 23.98/24.00/25/29.97/30.00/59.94/60.00/144 fps (40 to 533 MB/s)
6432 x 5360 up to 23.98/24.00/25/29.97/30.00/50/60.00 fps
12288 x 5112 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00/120 fps
9312 x 4896 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
8688 x 4896 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
8192 x 4608 up to 23.98/24.00/25/29.97/30.00/59.94/60.00 fps
8192 x 4320 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
8192 x 3408 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00/224 fps
4096 x 2680 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00/144 fps (10 to 135 MB/s)
4096 x 2304 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
4096 x 2160 up to 23.98/24.00/25/29.97/30.00 fps
3840 x 2160 up to 23.98/24.00/25/29.97/30.00/50/60.00 fps
4096 x 1704 up to 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps
1920 x 1080 up to 23.98/24.00/25/29.97/30.00/50/60.00 fps
Video Output via HDMI / SDI/BNC
3840 x 2160
1920 x 1080p
Fast-/Slow-Motion Support Slow-Motion Only
Built-In Microphone Stereo
Audio Recording 2-Channel, 24-Bit at 48 kHz
IP Streaming RTMP, SRT
1920 x 1080 at 60p
Interface
Media/Memory Card Slot No
Internal Storage 8 TB
Video I/O 2x BNC (12G-SDI) Output
Audio I/O 2x XLR 3-Pin Mic/Line Input (+48 V Phantom Power)
1x 1/8" / 3.5 mm TRRS Headphone/Mic Output
Power I/O 1x LEMO 8-Pin (12 to 24VDC) Input
1x LEMO 7-Pin (12 to 24VDC) Output
1x Fischer 3-Pin (12 to 24VDC) Output
Other I/O 2x USB-C (Camera Interface) Input/Output
1x USB-C (Firmware)
1x RJ45 (10 Gigabit Ethernet) Control/Data/Monitor/Video Input/Output
1x BNC (Reference, Timecode) Data Input
Wireless Wi-Fi
Mobile App Compatible Yes: iOS Only
App Name: Blackmagic Camera Control
Functionality: Remote Control
Global Positioning (GPS, GLONASS, etc.) No
Monitor
Display Type Primary Monitor: Articulating 5" Touchscreen LCD
Status Display: Fixed Non-Touchscreen LCD
Resolution Primary Monitor: 1920 x 1080
Power
Battery B-Mount
Environmental
Operating Conditions 32 to 104°F / 0 to 40°C up to 90% Humidity
Storage Conditions -4 to 113°F / -20 to 45°C up to 90% Humidity
General
Tripod Mount 4x 3/8"-16 Female (Top)
3x 1/4"-20 Female (Top)
5x 3/8"-16 Female (Bottom)
4x 1/4"-20 Female (Bottom)
Netflix Approved Yes
Materials Carbon Fiber, Magnesium Alloy
Dimensions (W x H x D) 22.5 x 18 x 10.25" / 57.1 x 45.7 x 26.04 cm
Weight 29.8 lb / 13.5 kg (Body Only)
