Draper 140039CB Access V, 137", 16:10, CineFlex CH1200V, 110 V

Draper 140039CB Access V, 137", 16:10, CineFlex CH1200V, 110 V

The Draper 140113CB is professionally designed as the perfect choice for use in home theaters, boardrooms, classrooms or mid-sized training rooms, this Access V is created offering a premium electric projection screen for use in small-to medium-sized spaces. This tab-tensioned screen is made for providing a perfectly flat viewing surface that comes with better image quality. RF welded tabs are intended for the creation of a more durable seal that is capable to eliminate the stickiness and separation. Its placement of the ceiling-recessed case during the initial phase of construction that is eliminating the job site damage and also allowing for the installation of screen at a later time. The bottom closure panel is designed for providing access to all components for having an easier service and maintenance.

• Surface Material: CineFlex CH1200V
• Image Format: 16:10
• Diagonal (Image area): 137" (72 1/2" x 116")
• Voltage: 110V
• Motor Options: Standard

• Case dimensions are 7-3/8" high x 8-1/16" deep (19 cm x 20 cm), includes trim flange. Built-in controls may increase case length. Mounting brackets may add to case dimensions, see Submittal in the Technical Documents tab for details.

•  Maximum image width up to 16' (488 cm) wide, depending on surface selection.

•  The standard Access is a good alternative whenever the above-ceiling space permits. Access Fit is recommended when space is at a premium.

•  Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.

•  Adjustable or removable hoisting brackets included for easy lifting during installation.

•  Sliding brackets on top of the case allow for adjustments for mounting.

•  Sliding brackets inside case accommodate different size screens.

•  Bottom closure panel detachable or hangs in place with “T” bracket to provide accessibility for service or maintenance.

•  Quick-connect wiring allows for early installation of the case with the addition of the screen later.

•  Low voltage, video interface or other controls can be built into housing for below ceiling access.

•  Includes a 110V, 3-position switch (standard). Quiet, low voltage motors and 220V options are available.

•  White case standard, black available upon request.

•  Custom sizes available.
