Tascam CD-RW901MKII CD RECORDER

Tascam CD-RW901MKII CD RECORDER

The CD-RW901MKII from Tascam is a professional CD recorder that is professionally designed using a high-performance AKM audio codec and comes featuring a gapless recording, analog and digital inputs and more.

The recorder is deisgned using the AKM AK4528VM codec which comes featuring an 24-bit AD/DA conversion for clean, clear sound quality along with a frequency response of 20 Hz to 20 kHz +/-0.8dB. This high-performance codec is capable of capturing audio along with a wide dynamic range intended for optimal CD recording.

The CD-RW901MKII also comes featuring a balanced analog XLR inputs and outputs for use along with pro audio equipment such as analog consoles and summing mixers. AES/EBU connectivity is also comes included for use along with digital mixers and processors.

The recorder is built also capable of displaying the ISRC (International Standard Recording Code) during mastering and capable of checking the data on a master disk after mastering. The ISRC is an international standard code used for identifying specific sound recordings.

Features

• L/R analog and digital input leveling provides accurate level control
• Supported media: CD-R, CD-R-DA, CD-RW, CD-RW-DA
• High speed CD-RW Supports
• CD drive supports playback of CD-DA and Data-CD
• Proprietary TEAC tray drive
• OPC (optimum power control) function: Adjusting the laser power for each disc type
• Fade-in/Fade-out recording function (1 to 30 seconds, 1 seconds increments)
• Sync recording function: Automatically start/stop recording at a preset level (-24dB to -72dB, 6dB increments)
• Digital volume for adjusting recording level accurately (-∞, 54.0dB to 18.0dB)
• Automatic track division: Automatically insert a track division at a preset condition
• Manual track division: Insert a track division by manual operation
• Time track division: Automatically insert a track division per preset interval (1 to 10 minutes, 1 minutes increments)
• Rec-mute function: Recording four seconds of silence on the disc
• Selectable maximum recording track numbers (automatically stop at preset number)
• Erase function: Erase selected track or disc (for CD-RW)
• Four playback modes (continuous, single, program, random)
• Repeat playback function (continuous, single, program, random, A-B)
• Fade-in/Fade-out playback function (OFF, 1 to 30 seconds, 1 seconds increments)
• Auto-cue function: Automatically pause by detection of a sound of start point in a track
• Auto-ready function: Automatically pause at head of next track after playback previous track
• Pitch control playback function: Pitch and speed can be varied (+/-16%, 0.1 to 1.0% increments, for CD-DA)
• Key control playback function: (b1 to b6, #1 to #6, half-note increments, for CD-DA)
• When using key control function with pitch control function, these function provides speed changing without changing pitch
• Timer playback function (external timer sold separately): Automatically begin playback when turned on
• Unfinalize function (for CD-RW): Erase TOC information of finalized CD-RW
• Time display switching (elapsed track/disc time, remaining track/disc time)
• CD-text editing supports
• PS/2 keyboard (sold separately) connection for remote control or entering a title
• SRC (sampling rate converter): Automatically convert the incoming frequency to 44.1kHz (for 32 to 48kHz)
• RCA analog unbalanced inputs/outputs
• COAXIAL digital input/output (IEC60958-3:S/P DIF)
• OPTICAL digital input/output (IEC60958-3:S/P DIF)
• Wireless remote controller with 10-key included (for CD-RW900MKII)
• Headphone output (20mW/ch)
• 3-polar AC sockets with the detachable AC cable
• 2U EIA rackmountable
• RoHS certified
• Sync trim function (+/-125 frame, +/-1.67 seconds)
• Automatic track division with trim function (+/-125 frame, +/-1.67 seconds)
• Selectable COPY ID (free/1 generation/prohibit/SCMS)
• Call function: Return to a point at which playback last started from ready mode
• EOM (end of message) function: EOM indicator will light-up before the end of track or disc (1 to 99 seconds)
• ISRC/RID code display function
• Time skip function: While in playback or ready, moves the playback point to forwards or backwards (1 seconds increments)
• Index search function: Search indexes within a track that were assigned during recording
• Overlap recording function: Using two-units CD-RW901MKII to make continuous recording
• Fader start/stop control via parallel control connector
• D-sub 9-pin RS-232C serial control connector
• D-sub 15-pin parallel control connector
• XLR analog balanced inputs/outputs
• XLR digital input/output (IEC60958-4:AES/EBU)
• Wired remote controller included
