YAMAHA VXC3F CEILING MOUNT COMMERCIAL 70 VOLT SPEAKER SYSTEM SINGLE UNIT

Vendor: Yamaha
Descriptions YAMAHA VXC3F CEILING MOUNT COMMERCIAL 70 VOLT SPEAKER SYSTEM SINGLE UNIT Yamaha VXC3F is a low profile ceiling speakers allow you to streamline the installation process for commercial and seamlessly integrate high-quality...
$139.50 $164.00
Color
White
Black

Descriptions

YAMAHA VXC3F CEILING MOUNT COMMERCIAL 70 VOLT SPEAKER SYSTEM SINGLE UNIT

Yamaha VXC3F is a low profile ceiling speakers allow you to streamline the installation process for commercial and seamlessly integrate high-quality audio into a restaurant, retail, or professional environment. Yamaha VXC3F featuring a renovated speaker unit that’s optimally tuned for music playback, the Yamaha VXC3F lightweight construction and flexible design can easily adapt to the strictest installation limitations, ensuring superb audio wherever they’re placed. The VXC3F speaker unit size and back box volume have also been matched to achieve well-balanced reproduction from low to high frequencies -even at low output levels. Also the Yamaha VXC3F ceiling speakers feature low profile back boxes, reduced weight, and mechanical features that contribute to significantly safer, faster installation. And since this Yamaha VXC3F support both low-impedance and high-impedance connection, the need for extra stock is minimized and systems can be designed to meet the requirements of any application.

Yamaha VXC3F Product Highlights

  • 3.5 inch full-range speaker unit
  • Engineered for optimum BGM reproduction
  • Direct support for low-impedance or high-impedance connections
  • Low-profile design facilitates installation in limited ceiling spaces
  • Built-in carrying band increases safety during installation
  • Anti-drop tab mechanism provide secure temporary positioning during installation
  • Double-threaded speaker clamp screws for speedy tightening
  • Paintable grilles with magnetic catches
  • Available in Black and White

Delivers the Highest Quality Background Music

Yamaha’s deep understanding of music comes together with cutting edge technology in newly designed speaker units and resin enclosures that allow an extraordinary degree of acoustic design freedom, resulting in refined, natural music reproduction at any volume level without the midrange distortion that often plagues speakers of this type. The VXC-F's speaker unit size and back box volume have also been painstakingly matched to achieve well-balanced reproduction from low to high frequencies even at low output levels.

General specifications



  • Speaker type - Full range, Bass reflex
  • Frequency range (-10dB) - 71 Hz – 20 kHz (Half-space:2π)
  • Nominal coverage - 140° conical (Half-space :2π)
  • Components LF-HF - 3.5” Full range unit
  • Power rating Noise - 20 W
  • Power rating PGM - 40 W
  • Power rating PEAK - 80 W
  • Nominal impedance - 8 Ω
  • Transformer taps 100V - 15W, 7.5 W, 3.8 W
  • Transformer taps 70V - 15 W, 7.5 W, 3.8 W, 1.9 W

SPL

  • Sensitivity (1W; 1m on axis) - 87 dB SPL (Half-space:2π)
  • Peak (Calculated) - 106 dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
  • I/O connectors - Euroblock (4 pin) × 1 (input: +/-, loop-thru: +/-)
  • Protection circuit / Load protection - Full-range power limiting to protect network and transducers
  • Finish - VXC3F: Black (approx. Munsell N3), VXC3FW: White (approx. Munsell N9.3)
  • Dimensions / Diameter - 285 (11-1/4")
  • Dimensions D - 112 mm (4-7/16")
  • Net weight - 2.5 kg (5.5 lbs)
  • Cutout size - Ø247 mm (Ø9-3/4")
  • Required ceiling board thickness - 5 mm – 37 mm
  • Accessories - O-ring, Tile Rail, Cutout Template, Euro Block (4pin), Terminal Cover
  • Packaging - Packaged in pairs
  • Certificate - UL1480, NFPA70, CE, EAC, RoHS
  • Others - Conduit tube: Ø15.4 mm - Ø21.3 mm
