YAMAHA VXC6 CEILING COMMERCIAL 70 VOLT 6" 2-WAY CEILING SPEAKERS SINGLE UNIT

Vendor: Yamaha
Descriptions YAMAHA VXC6 CEILING COMMERCIAL 70 VOLT  6" 2-WAY CEILING SPEAKERS SINGLE UNIT The 6.5 inch Yamaha VXC6 Full range loudspeaker has an interna; transformer that allows both high and low impedance drive...
$161.00 $189.00
Color
White
Black

Descriptions

YAMAHA VXC6 CEILING COMMERCIAL 70 VOLT  6" 2-WAY CEILING SPEAKERS SINGLE UNIT

The 6.5 inch Yamaha VXC6 Full range loudspeaker has an interna; transformer that allows both high and low impedance drive with just a single speaker, simply and easy switching the tap on the baffle. The Yamaha VXC6 single speaker can be used for both operations, inventory control is simplified and you can easily adapt your system to any changes. Yamaha VXC6 speaker has a unique features the Anti-Drop tab allows them to be mounted temporarily in the ceiling, freeing your hands for better and safety and ease of installation. Yamaha VXC6 has an attached, flexible carrying band also makes the speakers very portable, allowing you to carry multiple speakers at once safely. In addition the Yamaha VXC6 speaker comes with complete O-rings and tile rails for a safer and smoother installation.

Yamaha VXC6 feature newly customized transducers with large, powerful magnetic circuits that increase driving and braking force substantially, as well as dedicated tweeter diaphragms and speaker cone paper made from a carefully-created blend of materials that help optimize sound reproduction. Cabinets are built tough to meet the demands of a wide variety of commercial environments, constructed from a carefully selected plastic with just the right tensile strength, and designed with optimized bass-reflex tuning to offer a firm, tight low-end. From the networking components and the materials used for wiring and soldering, right down to the optimal placement of acoustic absorption material, a great deal of attention has been paid to even the smallest details of the series' design.

Yamaha VXC6 Product Highlights

  • Ceiling speakers for any application
  • Safe, seamless installation
  • Hexagonal design featured on the grille of speaker improves sound clarity
  • Can be mounted closely to the wall
  • Unrestricted woofer movement

A versatile lineup for clear consistent sound

Yamaha designed the new VXC and VXS speakers to accommodate a growing list of applications in the installation market. While these speakers deliver quintessential Yamaha sound quality, they have also been carefully designed for safe and easy installation. Featuring both ceiling and surface mount options, these speaker series include a comprehensive range of models that are available in either black or white, or can be painted to match the interior of any application.

General specifications

  • Speaker type - 2-way, Acoustic suspension
  • Frequency range (-10dB) - 56Hz - 20kHz (Half-space:2π)
  • Nominal coverage - 110° conical (Half-space:2π)
  • Components LF - 6.5" Cone
  • Component HF - 0.75" Soft dome
  • Power rating NOISE - 75W
  • Power rating PGM - 150W
  • Power rating PEAK - 300W
  • Nominal impedance -
  • Transformer taps 100V - 60W (170Ω), 30W (330Ω), 15W (670Ω)
  • Transformer taps 70V - 60W (83Ω), 30W (170Ω), 15W (330Ω), 7.5W (670Ω)

SPL

  • Sensitivity (1W; 1m on axis) - 86dB SPL (Half-space:2π)
  • Peak (Calculated) - 111dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
  • I/O connectors - 1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
  • Finish - VXC6: Black / VXC6W: White
  • Dimensions Diameter - 286mm (11.3")
  • Dimensions D - 205mm (8.1")
  • Net weight - 4.4kg (9.7lbs)
  • Cutout size - Ø247 mm (Ø9 3/4")
  • Required ceiling board thickness - 5 mm – 35 mm
  • Accessories - O-ring, Tile Rail, Cutout Template
  • Packaging - Packaged in pairs
  • Certificate - UL1480, UL2043, NFPA70, CE, EAC, RoHS
