YAMAHA VXC8 CEILING COMMERCIAL 70 VOLT 8" 2-WAY CEILING SPEAKERS SINGLE UNIT

Vendor: Yamaha
Descriptions YAMAHA VXC8 CEILING COMMERCIAL 70 VOLT 8" 2-WAY CEILING SPEAKERS SINGLE UNIT The 8 inch Yamaha VXC8 Full range loudspeaker has an internal; transformer that allows both high and low impedance drive...
$229.00 $269.00
Color
White
Black

Descriptions

YAMAHA VXC8 CEILING COMMERCIAL 70 VOLT 8" 2-WAY CEILING SPEAKERS SINGLE UNIT

The 8 inch Yamaha VXC8 Full range loudspeaker has an internal; transformer that allows both high and low impedance drive with just a single speaker, simply and easy switching the tap on the baffle. The Yamaha VXC8 single speaker can be used for both operations, inventory control is simplified and you can easily adapt your system to any changes. Yamaha VXC8 speaker has a unique features the Anti-Drop tab allows them to be mounted temporarily in the ceiling, freeing your hands for better and safety and ease of installation. Yamaha VXC8 has an attached, flexible carrying band also makes the speakers very portable, allowing you to carry multiple speakers at once safely. In addition the Yamaha VXC8 speaker comes with complete O-rings and tile rails for a safer and smoother installation.

Yamaha VXC8 feature newly customized transducers with large, powerful magnetic circuits that increase driving and braking force substantially, as well as dedicated tweeter diaphragms and speaker cone paper made from a carefully-created blend of materials that help optimize sound reproduction. Cabinets of this Yamaha VXC8 are built tough to meet the demands of a wide variety of commercial environments, constructed from a carefully selected plastic with just the right tensile strength, and designed with optimized bass-reflex tuning to offer a firm, tight low-end. From the networking components and the materials used for wiring and soldering, right down to the optimal placement of acoustic absorption material, a great deal of attention has been paid to even the smallest details of the series' design.

Several aspects of these Yamaha VXC8 speakers' design reflect a strong emphasis on functionality as well as the aesthetic features of their construction—effectively enhancing sound quality and speaker performance without disturbing the interior décor of the installation. This concept is evident in the hexagonal design featured on the grille of both series' speakers that actually improves sound clarity by raising the aperture ratio. Similarly, the smooth curves of the surface-mount cabinet's simple yet sophisticated design allow the speakers to be mounted closely to the wall—while still fully capable of panning and tilting to target service areas. Even the innovative design of the Yamaha VXC8 tweeter improves sound clarity by providing unrestricted woofer movement.

Yamaha VXC8 Product Highlights

  • Ceiling speakers for any application
  • Safe, seamless installation
  • Features newly customized transducers for superb music reproduction as well as crystal clear announcements
  • Hexagonal design featured on the grille improves sound clarity
  • Can be mounted closely to the wall
  • Unrestricted woofer movement

A versatile lineup for clear consistent sound

Yamaha designed the new VXC and VXS speakers to accommodate a growing list of applications in the installation market. While these speakers deliver quintessential Yamaha sound quality, they have also been carefully designed for safe and easy installation. Featuring both ceiling and surface mount options, these speaker series include a comprehensive range of models that are available in either black or white, or can be painted to match the interior of any application.

General specifications

  • Speaker type - 2-way, Acoustic suspension
  • Frequency range (-10dB) - 55Hz - 20kHz (Half-space:2π)
  • Nominal coverage - 100° conical (Half-space:2π)
  • Components LF - 8" Cone
  • Components HF - 1" Soft dome
  • Power rating Noise - 90W
  • Power rating PGM -  180W
  • Power rating PEAK - 360W
  • Nominal impedance -
  • Transformer taps 100V - 60W (170Ω), 30W (330Ω), 15W (670Ω)
  • Transformer taps 70V - 60W (83Ω), 30W (170Ω), 15W (330Ω), 7.5W (670Ω)
  • SPL Sensitivity (1W; 1m on axis) - 90dB SPL (Half-space:2π)
  • SPL Peak (Calculated) - 116dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
  • I/O connectors - 1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
  • Finish - VXC8: Black / VXC8W: White
  • Dimensions Diameter - 325mm (12.8")
  • Dimensions D - 259mm (10.2")
  • Net weight - 6.6kg (14.6lbs)
  • Cutout size - Ø285 mm (Ø11 1/4")
  • Required ceiling board thickness - 5 mm – 35 mm
  • Accessories - O-ring, Tile Rail, Cutout Template
  • Packaging - Packaged in pairs
  • Certificate - UL1480, UL2043, NFPA70, CE, EAC, RoHS
