Audix AP41HT7BGB, WIRELESS,R41,BODY PACK, W/HT7, BEIGE, WIRELESS,R41,BODY PACK, W/HT7, BEIGE, Headset Wireless System (554 MHz - 586 MHz)

Vendor: Audix
Descriptions Audix AP41HT7BGB, WIRELESS,R41,BODY PACK, W/HT7, BEIGE, WIRELESS,R41,BODY PACK, W/HT7, BEIGE, Headset Wireless System (554 MHz - 586 MHz) The Audix AP41HT7BGB features its performance series single-channel bodypack wireless system form Audix and includes...
$839.00 $1,019.00
Title

Audix AP41HT7BGB, WIRELESS,R41,BODY PACK, W/HT7, BEIGE, WIRELESS,R41,BODY PACK, W/HT7, BEIGE, Headset Wireless System (554 MHz - 586 MHz)

The Audix AP41HT7BGB features its performance series single-channel bodypack wireless system form Audix and includes the R41 1-channel diversity receiver, B60 bodypack transmitter and black HT7 single-ear miniaturized condenser microphone. the R41 that includes in the Audix AP41HT7BGB receiver can operates on a frequency range of 554 MHz - 586 MHz and offers one-toch auto scan searches for clear channel. A big thanks to the one touch sync function, the Audix AP41HT7BGB receiver easily links to the B60 bodypack transmitter placed within 300'

The Audix AP41HT7BGB microphone can be connected to the bodypack transmitter via the integrated 3-pin mini XLR-terminated cable. This omnidirectional Audix AP41HT7BGB microphone features a comfortable ear piece that can be worn around the left or right ear with a durable adjustable length boom arm.

Audix AP41HT7BGB Product Features

R41 Diversity Receiver

  • 32 MHz Wide spectrum receiver
  • 106 Pre-coordinated frequencies for quick, easy and reliable set up
  • One-touch auto scan searches for clear channel
  • One-touch sync links transmitter to receiver via infrared beam

B60 Bodypack Transmitter

  • 64 MHz Wide spectrum transmitter
  • Durable metal housing
  • 10 Hour run time - AA batteries

HT7 Headworn Condenser Microphone

  • Hands free, headworn vocal microphone, available in Black or Beige

Available Frequency Bands

  • A = 522 MHz - 554 MHz
  • B = 554 MHz - 586 MHz

Audix R41 Kit-A Performance Series Single-Channel UHF Diversity Receiver (A: 522 To 554 MHz)<span> </span>Specs

Manufacturer Warranty
Frequency Band  522 to 554 MHz
Bandwidth  32 MHz
# Of Simultaneous Systems  Up to 16
Switchable Frequencies  106 pre-coordinated frequencies
Wireless Range  Up to 300' / 91 m
Antenna Connector  2 x BNC (8 VDC, 150 mA)
Outputs  1 x XLR 3-pin balanced
 1 x 1/4" TS unbalanced
Audio Output Level  XLR: -12 dBV at 25 kHz deviation, 600-Ohm   load, +6 gain
 1/4": -18 dBV at 25 kHz deviation, 10-Ohm load,   +6 gain
Audio Level Control  -12 to +9 dB in 3 dB steps
Frequency Response  45 Hz to 18 kHz
Compander  2:1
Pilot Tone  32 kHz
Receiving System  Single tuner, antenna diversity
Signal to Noise Ratio  105 dB at 30 kHz deviation (A-weighted)
Total Harmonic Distortion (THD)  ≤0.7% (33 kHz deviation at 1 kHz)
Sensitivity  5 dBµV (S/N 60 dB at 25 kHz deviation, A-   weighted)
Power Requirement  100 to 240 VAC, 50/60 Hz, 12 VDC, 1 A
Dimensions (W x D x H)  8.1 x 8.1 x 1.7" / 205 x 206 x 44 mm
Weight  1.9 lb / 0.9 kg



Audix B60 Performance Series Bodypack Transmitter (522 To 586 MHz)<span> </span>Specs

Manufacturer Warranty
RF Power Output  10/30 mW
Bandwidth  64 MHz
Gain Adjustment  0 dB, -6 dB, -12 dB, -24 dB
Inputs  1 x mini-XLR 3-pin
Input Impedance  Mic: 10 kOhms
 Line: 1 MOhm
Maximum SPL  Approximately 128 to 140 dB (depending on   microphone)
Battery Life  Approximately 14 hours
Current Consumption  110 mA typical
Power Requirement  2 x AA 1.5 V batteries
Dimensions (W x L x D)  2.6 x 3.5 x 0.7" / 67 x 90 x 17 mm
Weight  3 oz / 85 g without batteries
Audix HT7 Condenser Headworn Microphone (3-Pin Mini-XLR, Beige)<span> </span>Specs
General
Product Type  Microphone
Height  1.6 in
Weight  0.25 oz
Color  Beige
Body Material  Alloy steel
Recommended Use  Professional audio - voice, broadcast
Microphone
Type  Boom
Microphone Technology  Condenser
Microphone Operation Mode  Omni-directional
Connectivity Technology  Wired
Sensitivity  17 mV/Pascal
Impedance  2 kOhm
Frequency Response  20 - 20000 Hz
Max Sound Pressure  135 dB
Features  Phantom power
Connections
Connector Type  Microphone (3 pin mini-XLR)
Miscellaneous
Cables Included  Microphone cable - detachable - 4 ft
Included Accessories  Carrying pouch, foam windscreen
Manufacturer Warranty
Service & Support  Limited warranty - 1 year
