Biamp Systems SUB2400-BL, SUB2400-W Passive, 2 x 10-inch subwoofer | Black, White
Vendor: Biamp Systems
Available
Biamp Systems SUB2400-BL, SUB2400-W Passive, 2 x 10-inch subwoofer | Black, White
The Biamp Desono SUB2400 is a powerful dual 10-inch passive subwoofer designed to deliver deep, fast, and punchy bass with exceptionally high output and low distortion. Its compact design makes it an excellent choice for venues where dance-level music and powerful low-frequency performance are required, including bars, pubs, clubs, restaurants, and taverns. The SUB2400 features two separate bandpass chambers, each equipped with a 10-inch dual-coil woofer. Combined with push-pull technology, this configuration delivers impressive output from a relatively compact enclosure while significantly reducing distortion. The use of smaller 10-inch woofers also contributes to a faster and more responsive bass character compared with larger 15-inch or 18-inch subwoofer designs. This makes the SUB2400 particularly well suited to music applications where tight, energetic and impactful bass is essential. The SUB2400 offers selectable 4-ohm or 16-ohm operation using the large switch on the rear panel. The 16-ohm setting is particularly beneficial for long cable runs, helping reduce power losses while maintaining strong bass performance. It also allows multiple SUB2400 cabinets to be incorporated into a system. For a complete high-output system, the SUB2400 can be combined with MASK6 or MASK8 loudspeakers and the CHAMP-4 four-channel digital amplifier.
Features
- Zoom certified
- Smooth, strong bass response
- Dual coil 10-inch subwoofers in push-pull configuration
- Low frequency boost for distributed applications
- 600W power handling
- Switchable 4Ω or 16Ω impedance
- Suitable for in-wall, under-seating, under-stage and other “hidden” LF applications
- 5-year warranty
- Not available in U.S. and Canada
| GENERAL | |
| Height | 27.6 inches (700 mm) |
| Width | 13.9 inches (352 mm) |
| Depth | 17.7 inches (450 mm) |
| Weight | 64.4 lbs (29.2 kg) |
| Enclosure | Enclosure / Finish: Plywood, matte finish, Black Grille: Cloth, White (RAL 9003) or Black (RAL 9011), |
| Recommended Amplifiers | 250W - 750W @ 4Ω (49V - 69V) |
| ENVIRONMENTAL | |
| Operating Environment | Indoor |
| POWER | |
| Power | 600W Cont. 2400W Peak |
| CONTROLS & INDICATORS | |
| Control | Rocker switch for 4Ω or 16Ω operation |
| LOUDSPEAKER | |
| Loudspeaker Type | Dual 10-inch subwoofer |
| Operating Mode | Passive |
| Operating Range | 45 Hz - 150 Hz |
| Beamwidth | Omnidirectional |
| Sensitivity | (1W/1m) 99 dB |
| Drivers | LF 2 x 10 inches |
| AUDIO | |
| Input Type | 2 Speakon™ connectors wired in parallel |
| Impedance | 4Ω or 16Ω |
| Maximum Output | 127 dB 133 dB Peak |
| CERTIFIED SOLUTIONS | |
| Zoom | Zoom Certified |
| COMPLIANCE | |
| Environmental Ratings | IP20 per IEC 60529 |
