Clear-Com RCS-2700, 8x24 Ch. program station assignment panel

Clear-Com RCS-2700, 8x24 Ch. program station assignment panel

Clear-Com RCS-2700 features a Programable Channel Assignments it is remotely switch partyline assignments for medium to large systems with sources from a partyline interface or matrix system to a beltpack or other interface channel. The Clear-Com RCS-2700 also features the Real-time or Offline Program Software, RCS-2700 configure program assignments with a virtual panel on your PC in real-time, when connected, or offline, by saving pre-set information in non-volatile memory. The Clear-Com RCS-2700 has eight 24-channel programmable station-assignment panel. Stores 14 presets and expandable up to 15 sources and 72 destinations. Assigns 24 stations or groups to one of eight party-line channels. 2RU rack mount. See also RCS-WIN software.

Clear-Com RCS-2700 Product Features

• 8-Source x 24-Destination Programmable Assignment Panel
• Expandable up to 15 sources x 72 destinations
• Stores 14 presets in non-volatile memory
• Multiple systems can be controlled from the same PC
• Latching relays keep current draw extremely low
• TW compatible
• Front panel security lockout
• Easy-to-wire Euro-terminal blocks for rear panel connections
• External contact closure input for remote preset selection
