Electro Voice QRX-112/75-BLK 12-inch two-way, 75° x 50° , 300 watts, passive/bi-amp, flying, pole mount, black
Vendor: Electro Voice
Available
Electro Voice QRX-112/75-BLK 12-inch two-way, 75° x 50° , 300 watts, passive/bi-amp, flying, pole mount, black
The Electro Voice QRX-112/75-BLK is a black, one of the QRx series, has become the standard for regional sound companies, rental professionals, and contractors who want compact high-performance loudspeakers with concert-grade EV components. It is enclosed in a rugged EVCOAT, Electro Voice QRX-112/75-BLK is looking great stacked as monitors, on poles, or even flown with simple, integrated, L-track rigging points. Its asymmetrical horns which are unique, fully-rotable have a 15-degree downward bias for ensuring a high-frequency coverage without needing to tilt the enclosure toward the audience. Our powerhouse DH7 large-format driver (three-inch voice-coil, 1.4-inch exit) is providing the high-frequency engine, and a selection of DL and EVX woofers anchor the low and sub frequencies at the same time. The combination of versatility, unique design, and high-level components are all making it one of the best values in the industry.
Features
- Compact with high output
- Ideal for mains (small-to-medium rooms) or monitors
- Cast-frame woofer, vented cabinet for extended LF
- 3-inch DH7 titanium HF compression driver
- Rotatable 75º x 50º Constant-directivity horn
- Asymmetric 10º down-angled coverage
- Externally switchable bi-amped or passive operation
- High sensitivity, 131 db maximum SPL (peak)
- Power handling: 300 W continuous, 1200 W peak
- 5-sided 13-ply birch enclosure with monitor slant
- Built-in handles and L-Track rigging
| Frequency Range (-10 dB) | 52 - 18000kHz |
| Weight Net | 57.32lbs (26kg) |
| Depth | 14.65" (372mm) |
| Width | 15.35" (390mm) |
| Height | 26.57" (675mm) |
| Available Color | Black, White, Unfinished |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 98dB (Passive) |
| Chassis Size | 304.8 mm |
| Coverage (Nominal -6 dB) H | 75° |
| Coverage (Nominal -6 dB) V | 50° |
| Crossover Frequency | 1500Hz (24 dB/octave) |
| Enclosure Material | 13-ply birch plywood |
| Family | QRx |
| Flying | Yes |
| Frequency Response (-3 dB) | 75 - 15000Hz |
| HF Nominal Impedance | 8Ω |
| HF Power Handling | 75Watts |
| HF Transducer | 3-inch DH7 |
| Input Connections | Parallel Neutrik® NL4 |
| LF Nominal Impedance | 8Ω |
| LF Power Handling | 300Watts |
| LF Transducer | 12-inch DL12BFH |
| Max. SPL/1m (calc) | 131dB |
| Nominal Impedance (Passive) | 8Ω |
| Powered or Passive | Passive |
| Recommended High-Pass Frequency | 45Hz (12 dB/octave) |
| Rotatable Horn | Yes |
| Sensitivity 1 W/1 m | 98dB |
| Speaker Type | Full-Range, Mid-High, Two-Way, Wedges |
| System Power Handling (Continuous/Program/Peak) | 350//1400Watts |
| Weatherized | No |
| Woofer Size | 12inch |
