YAMAHA VXL1W-16 16 FULL RANGE 1.5" DRIVERS - Slim line array loudspeaker

YAMAHA VXL1W-16 16 FULL RANGE 1.5" DRIVERS - Slim line array loudspeaker

The Yamaha VXL1W-16 series line source loudspeakers offer a unique combination of outstanding sound quality and slim form-factor that is ideal for a variety of environments. The Yamaha VXL1W-16 line source loudspeakers offer excellent projection as well as uniform volume and sound quality over a wide listening area, making them a great choice for highly reflective rooms, lecture halls, conference rooms, and other facilities that require maximum intelligibility throughout the listening area. The Yamaha VXL1W-16 featuring 1.5-inch full-range drivers, that can be combined to optimally serve a variety of installations and spaces. The Yamaha VXL1W-16 is slim as 2.1 inches (54mm) wide enclosures feature elegantly curved grille designs that blend beautifully with any décor to deliver a superior and uniform speech and music reproduction in a wide variety of applications.

Yamaha VXL1W-16 Product Highlights

• 1.5 inch (3.75 cm) full-range loudspeaker units with neodymium magnets
• 170° horizontal dispersion for uniform SPL over a wide listening area
• Vertical coverage can be selected as 20°(Standard) or 40°(Wide)
• Slim design complements any interior décor
• Available in black or white
• Enclosures can be painted to match the surroundings
• Wall mount bracket supplied
• Optional hardware for a wide range of installation needs

Sleek. Smart. Sound.

VXL series line source loudspeakers offer a unique combination of outstanding sound quality and slim form-factor that is ideal for a variety of environments. VXL line source loudspeakers offer excellent projection as well as uniform volume and sound quality over a wide listening area, making them a great choice for highly reflective rooms, lecture halls, conference rooms, and other facilities that require maximum intelligibility throughout the listening area.

The VXL series includes three models VXL1-8, VXL1-16, and the VXL1-24 each featuring 1.5-inch full range drivers, that can be combined to optimally serve a variety of installations and spaces. The slim 2.1-inch (54mm) wide enclosures feature elegantly curved grille designs that blend beautifully with any décor to deliver a superior and uniform speech and music reproduction in a wide variety of applications.

General Specifications

• Speaker type - Full-range, Bass-reflex
• Frequency range (-10dB) - 81 Hz – 20 kHz *1 108 Hz - 20kHz 1 (w/ port cover)
• Coverage area - Horizontal: 170°, Vertical:20°（ +10° – -10°） (NORMAL), 40°（+10° – -30°） (WIDE)
• Components LF-HF - 1.5” (3.75 cm) Cone × 16
• Power rating NOISE - 80 W
• Power rating PGM - 160 W
• Power rating PEAK - 320 W
• Nominal impedance - 12Ω
• SPL Sensitivity (1W; 1m on axis) - 91 dB SPL (1 m/1 W) *1 *2
• SPL Peak (Calculated) - 116 dB SPL (1 m) *3
• I/O connectors - Euroblock (2 pin) × 2 (input: +/-) Max. wire size AWG 12 (3.3 mm²)
• Protection circuit Load protection - Full-range power limiting to protecting network and transducers
• Finish - VXL1B-16: Black painting (approximate value: Munsell N3.0), VXL1W-16: White painting (approximate value: Munsell N9.0)
• IP-Rating - Dust and water-resistant : IP35
• Packaging - Packaged in 1 pc
• Dimensions (W x H x D) - 2.1 x 33.3 x 4.1 in. (54 x 846 x 104 mm) - Speaker Only, 2.1 x 33.3 x 4.4 in. (54 x 846 x 111.5 mm) - with Included Bracket
• Weight - 3.9 kg / 8.6 lbs (Speaker only)
