YAMAHA VXS10S 10" SURFACE MOUNT SUBWOOFER LOW IMPEDANCE FOR STUDIO OR LIVE USE

Vendor: Yamaha
YAMAHA VXS10S 10" SURFACE MOUNT SUBWOOFER LOW IMPEDANCE FOR STUDIO OR LIVE USE  The Yamaha VXS10S has features of two-full-range models and two subwoofers, allowing you to choose the optimal for a particular...
$409.99 $599.00
Color
White
Black

YAMAHA VXS10S 10" SURFACE MOUNT SUBWOOFER LOW IMPEDANCE FOR STUDIO OR LIVE USE

The Yamaha VXS10S has features of two-full-range models and two subwoofers, allowing you to choose the optimal for a particular application and, if necessary, combine it with a subwoofer for revenues that require a stronger bottom ends. Yamaha VXS10S is a full-range models are equipped with internal transformers that allow them to operate at both high or low impedance simply by changing the tap on the rear of the speaker.

Also the Yamaha VXS10S offer IP45-rated protection, ensuring worry free use in outdoor applications. VXS10S speaker come with a dedicated bracket for safe, trouble free speaker installation. You can temporarily mount your Yamaha VXS10S speaker to freeing your hands to adjust mounting angles, which can now configured consistently with ease, thanks to the gear guides in the bracket connectors. Additionally the bracket base of the Yamaha VXS10S allows the speaker to be mounted on both walls and ceilings without the need to prepare a different set of brackets.

Both series feature newly customized transducers with large, powerful magnetic circuits that increase driving and braking force substantially, as well as dedicated tweeter diaphragms and speaker cone paper made from a carefully-created blend of materials that help optimize sound reproduction. Cabinets are built tough to meet the demands of a wide variety of commercial environments, constructed from a carefully selected plastic with just the right tensile strength, and designed with optimized bass-reflex tuning to offer a firm, tight low-end.

Several aspects of these speakers' design reflect a strong emphasis on functionality as well as the aesthetic features of their construction—effectively enhancing sound quality and speaker performance without disturbing the interior décor of the installation. This concept is evident in the hexagonal design featured on the grille of both series' speakers that actually improves sound clarity by raising the aperture ratio. Similarly, the smooth curves of the surface-mount cabinet's simple yet sophisticated design allow the speakers to be mounted closely to the wall—while still fully capable of panning and tilting to target service areas. Even the innovative design of the VXC's tweeter improves sound clarity by providing unrestricted woofer movement.

Product Highlights of Yamaha VXS10S

  • Versatile low-impedance subwoofer
  • Sound and size ideally matched to the VXS and VXC series
  • Bass-reflex design ensures smooth, distortion-free low-frequency extension
  • Dual voice coil configuration supports stereo sources
  • Satellite connectors for easy setup
  • Dedicated wall-mount hardware supplied
  • Black and white models available
  • Recommended satellite speakers: VXS3F, VXS5, VXS8, VXC4, VXC6, VXC8, VXC3F

Naturally Extended Lows Bring the Music to Life

VXS series “S” model subwoofers are ideal matches for VXS and VXC series speakers, smoothly extending the low frequency range with superb sonic quality for bigger, more true-to-life musical reproduction. Although no larger than a compact surface-mount speaker the VXS3S delivers solid, natural-sounding low-end reinforcement, while the VXS10S and VXS10ST make even more low-frequency power available for situations that require maximum bass authority.

General specifications

  • Speaker type - Bass-reflex type Subwoofer
  • Frequency range (-10dB) - 45Hz - 250Hz
  • Components LF - 10" Dual Voice Coil
  • Power rating NOISE - 100W + 100W
  • Power rating PGM - 200W + 200W
  • Nominal impedance - 8Ω + 8Ω
  • Satellite impedance - 8Ω load per satellite output recommended *2
  • SPL Sensitivity (1W; 1m on axis) - 96dB SPL *3
  • SPL Peak (Calculated) - 125dB SPL *4
  • I/O connectors - Input: 1x Euroblock (4P)(CH1: + / -, CH2: + / -), Satellite Output: 1x Euroblock (4P)(ST 1: + / -, ST 2: + / -)
  • Protection circuit Load protection - Full-range power limiting for protecting network and transducers
  • Shape - Rectangular
  • Cabinet material - MDF
  • Finish - VXS10S: Black (approximate value:Munsell N3), VXS10SW: White (approximate value:Munsell 3.5PB9.0/1)
  • Dimensions W - 260mm (10.2") *5
  • Dimensions H - 500mm (19.7") *5
  • Dimensions D - 389mm (15.3") *5
  • Net weight - 16.5kg (36.4lbs) *5
  • Accessories - Wall mount bracket
  • Packaging - Packaged each
  • Certificate - CE, EAC, RoHS
