Yamaha XMS06S4-D 4-Channel Power Amplifier with DSP and Power Sharing, Dante-Enabled, 600W Total, Lo-Z/Hi-Z, 1U

Yamaha XMS06S4-D 4-Channel Power Amplifier with DSP and Power Sharing, Dante-Enabled, 600W Total, Lo-Z/Hi-Z, 1U

The Yamaha XMS Series combines intelligent power management, onboard DSP, and flexible system control to simplify the design and operation of installed audio systems. With eight models covering analog and Dante inputs, four- and eight-channel configurations, and multiple output power options, the XMS Series gives system designers the flexibility to build installations around their specific requirements. One of the defining features of the XMS Series is its intelligent power sharing across groups of four output channels. Rather than limiting each channel to a fixed amount of available power, the amplifier intelligently distributes resources across the group. ProVisionaire Design automatically calculates and configures the power allocation based on the selected Yamaha speakers, reducing the need for manual calculations and helping ensure each output receives the appropriate power.

The integrated routing function further simplifies system design by allowing a single audio source to be distributed across multiple zones within each four-channel group without requiring additional hardware. This provides greater flexibility for installations where multiple areas need to share the same source. Yamaha speaker presets go beyond conventional EQ settings. Each preset incorporates optimized limiter settings designed to balance sound quality with long-term speaker protection. Through ProVisionaire Design, installers can access detailed parameters across the entire XMS lineup while maintaining a consistent and scalable Commercial Installation Solutions (CIS) workflow.

Commissioning is also streamlined through the full-color front-panel LCD, which provides system status and key parameters directly on the amplifier without requiring a laptop. When an issue occurs, the display can show an alert together with a QR code linking to corrective guidance, helping installation personnel quickly identify the appropriate solution and minimize troubleshooting time.

Features

• Power Sharing technology dynamically allocates amplifier power across channels for maximum flexibility and efficient system design.
• Supports both Hi-Z and Lo-Z speaker configurations with per-channel settings.
• Available in 4-channel and 8-channel models with Dante and non-Dante versions.
• Built-in DSP includes speaker processing, EQ, delay, limiter, and matrix routing capabilities.
• Integrated matrix router enables flexible signal routing without requiring an external processor in many applications.
• Unified workflow and simplified setup through Yamaha ProVisionaire Design software.
• Compact, space-saving design with 4-channel models in a 1U chassis.
• Front-panel LCD and intuitive controls enable quick setup and monitoring directly from the amplifier.
• Dante models support redundant and daisy-chain network configurations, plus AES67 and DDM compatibility.
• 4ch in 1U with built-in DSP and Dante
• Total output power 600W
• Max output power 300W/ch at 4,8Ω when power sharing
• Dante sampling frequency rate up to 96kHz

• Total Output Power
  • 1~4ch=600W
• Max Output Power Per Channel
  • Lo-Z 4Ω: 300W
  • Lo-Z 8Ω: 300W
  • Hi-Z 100V: 150W
  • Hi-Z 70V: 150W
• Control
  • Front Panel: Panel POWER switch, Rotary encoder and switches for GUI control
  • I/O Connectors
    • Analog Input: Euroblock 3.5mm pitch 12 pin ×1
    • Digital Input/Output: RJ-45 x2(PRIMARY/SECONDARY)
    • Speaker Output: Euroblock 7.62mm pitch 8 pin ×1
    • Network: RJ-45 x1
    • Remote, Fault output: Euroblock 3.5mm pitch 6 pin x1
    • AC IN: AC inlet x1
• Power requirements: 100V-240V 50Hz/60Hz
• Dimensions (W x H x D)
  • 480 x 44 x 444 mm (1U)
  • (18.9 x 1.8 x 17.5 inch)
• Weight 6.8kg (15.0 lbs)
